Short answer: lithium iron phosphate (LiFePO4) is usually the better performance choice for frequent off-grid use, high inverter loads and weight-sensitive builds. AGM remains a sensible lower-upfront-cost option for modest loads, occasional trips or a compatible system that does not justify a full conversion.
Practical comparison
| Factor | LiFePO4 lithium | AGM lead-acid |
|---|---|---|
| Usable energy | A larger share of rated capacity is commonly usable when operated within the maker’s limits | Conservative cycling generally uses a smaller share of rated capacity |
| Weight | Much lighter for similar usable energy | Heavier |
| High-current loads | Often strong, subject to BMS and cell limits | Voltage sag can be greater; size the bank carefully |
| Charging | Requires compatible profiles and temperature controls | Widely supported by existing chargers |
| Upfront cost | Higher | Lower |
| System complexity | BMS, compatible charging and correct installation are essential | Simpler in many older caravans, but still needs correct protection and ventilation |
Do not compare amp-hours alone
A 100Ah label does not tell you usable energy, permitted discharge current or expected cycle life. Compare watt-hours that you can actually use within the manufacturer’s operating limits. Also compare total bank weight, charge time, warranty conditions and current delivery for your inverter.
Build a load list first with our battery-capacity calculator. A fridge-and-lights setup has different needs from induction cooking, an espresso machine or air conditioning.
Conversion questions people miss
- Does the 240V charger have an approved lithium profile?
- Can the solar regulator and tow-vehicle DC-DC charger be configured correctly?
- Will the alternator connection be current-limited and isolated as required?
- Does the inverter’s continuous and surge current fit inside the battery BMS limit?
- Is there compliant over-current protection close to the battery and safe isolation?
- Is the proposed battery location permitted by the battery maker and applicable installation rules?
A “drop-in replacement” claim does not remove the need to assess the whole system. A charger that reaches the wrong voltage, a cable that was adequate for a small AGM load, or an unsuitable enclosure can undermine the upgrade.
Temperature and storage
Many LiFePO4 batteries restrict charging below a specified cell temperature unless they include managed heating. Check the exact manual if you tour alpine areas. High heat also affects battery life, so avoid engine bays or sealed compartments unless the product is explicitly approved for that environment.
AGM batteries have their own limits. They are heavy, voltage falls during discharge, and repeated deep discharge can shorten service life. Both chemistries need the correct storage state and charger behaviour.
Safety matters more than the label
Lithium-ion battery incidents can involve intense fire, toxic gases and re-ignition. The ACCC advises using reputable products, following manufacturer instructions and stopping use if a battery shows swelling, leaking, unusual heat, odour or damage. LiFePO4 is a particular lithium-ion chemistry, but it still requires a functioning BMS, correct charging, secure mounting and protection from damage.
Which battery suits you?
- Choose lithium for frequent off-grid touring, tight payload, faster recharge and substantial inverter loads—provided the full system is designed for it.
- Choose AGM for low daily use, occasional weekends, cold-weather simplicity or when a safe compatible system already meets your needs.
- Delay the purchase if you have not weighed the caravan or defined your loads. The best chemistry cannot fix insufficient payload or undersized wiring.
For a plain-language foundation, see caravan battery capacity explained and the 12V Power Basics guide.
An Australian touring scenario
A weekend traveller using LED lights, a water pump and a small compressor fridge may find an existing AGM bank entirely adequate, especially when it is charged on a powered site between trips. A full-time couple running induction, laptops and a large inverter can benefit from lithium’s lower weight and greater usable energy, but their conversion may also require a new charger, DC-DC unit, solar settings, monitoring and heavier conductors. The battery price is only one line in the system comparison.
Limits of brochure comparisons
Lithium is a family of chemistries. For caravans, LiFePO4 is common, but the cell chemistry does not make every product equivalent. Compare enclosure rating, BMS protections, cell balancing, continuous and surge current, low-temperature behaviour and warranty exclusions. For AGM, compare the manufacturer’s recommended depth of discharge, cycle data at that depth, charge voltages and standby maintenance. Marketing cycle-life numbers are meaningful only when the test conditions are stated.
What to verify before buying or changing the system
- Battery chemistry and a complete Australian data sheet
- Usable capacity at the planned discharge rate and temperature
- BMS continuous, surge and charge-current limits
- Compatibility of mains, solar and tow-vehicle charging equipment
- Low-temperature charge protection for alpine travel
- Permitted mounting orientation, enclosure and ventilation requirements
- Short-circuit protection, isolation and secure crash-resistant mounting
- Whole conversion price, installed weight and written warranty conditions
Ongoing operation and maintenance
Keep terminals protected and inspect mounts after corrugated-road travel. Review charger settings whenever equipment or firmware changes. Watch for a persistent imbalance, unexpected capacity loss, swelling, heat, smell or damaged cases, and stop using suspect batteries in line with manufacturer and ACCC guidance. Store the caravan using the battery maker’s recommended state of charge and isolation method; lithium and AGM storage routines can differ.
A fair way to compare quotes
Give every supplier the same written brief: travelling party, normal destinations, longest unserviced stay, existing equipment, available installation space and remaining payload. Ask for the exact model numbers and manuals rather than accepting a category description. The quote should separate hardware, installation, commissioning, certification where applicable and removal or safe decommissioning of old equipment. It should also state exclusions, warranty responsibility and the added installed mass.
Compare the proposals against the same ordinary worst case. For electrical systems, that may be consecutive cloudy days and the largest simultaneous load. For water or waste systems, it may be the longest stay before lawful refill or disposal. For fuel-burning equipment, include cold starts, ventilation, fuel availability and servicing. A design that works only under ideal sun, perfect coverage or unlimited site facilities is not a touring plan.
Score each option for five things: safety and compliance, fit with your actual travel, payload, daily effort and recoverability after a fault. Purchase price belongs in the comparison, but so do new chargers, tanks, vents, cabling, plumbing, certification and future consumables. Give extra weight to factors that can strand you or close access to a campsite.
Plan for a fault, not just normal operation
Ask what happens when the chosen system fails on a Sunday in a regional town. Identify the safe isolation method, what other equipment is affected, whether the caravan remains usable and which parts are realistically stocked in Australia. A highly integrated appliance can save space but may remove several functions at once. Separate systems can provide redundancy but add weight, connections and maintenance. There is no universal winner; record the consequence that matters to your trip.
Carry only the spares and tools the manufacturer permits an owner to use. Do not bypass fuses, pressure devices, ventilation, battery management or combustion safety controls to keep travelling. If a fault involves gas, 230V electricity, overheating, fumes, damaged lithium batteries or leaking waste, isolate the equipment if safe, move people away from the hazard and obtain qualified assistance.
Recheck the decision when your travel changes
A setup chosen for powered coastal parks may not suit a remote inland season. Revisit capacity, fuel, payload and service access after adding appliances, changing tow vehicles, travelling with more people or planning longer stays. Reweigh after material modifications and keep the measured axle and total masses with the system records. This prevents several individually reasonable upgrades from quietly consuming the safety margin.
When keeping the current system is sensible
An upgrade is not automatically progress. If the present equipment is safe, supported and reliably covers your ordinary trips, maintenance or a small complementary item may solve the real problem with less weight and complexity. Replace equipment when measured performance, route requirements, safety, serviceability or a clearly defined new use justifies the change—not simply because a newer technology is popular.
Commissioning and trip records
Before departure, ask the installer to demonstrate normal operation, isolation, alarms, fault messages and safe shutdown. Keep the manual, model and serial number, invoice, commissioning information and a simple diagram with the caravan records. On the first trip, note energy or fuel use, temperatures, refill or disposal intervals and any nuisance alarms. Those observations turn the next adjustment into evidence-based maintenance rather than guesswork.
Your practical next step
Complete a seven-day load table before choosing chemistry. Mark the largest simultaneous inverter load and the longest period without charging. Give that table to the installer with your payload limit. A quote that does not address those three facts is not yet a system design.
Sources and further reading
- ACCC lithium-ion batteries guide
- Victron Lithium Battery Smart manual
- REDARC lead-acid battery guide
Information checked 24 August 2026. Product specifications and campsite rules can change; confirm the current manual and local requirements before relying on them.
